Intel® Core i3/i5/i7/Celeron/Pentium LGA1151 Industrial Motherboard | Dual Gigabit LAN | 3 Display Outputs | 6x COM Ports | PCI Slots

Maximize your industrial computing performance with the Intel® Core i3/i5/i7/Celeron/Pentium LGA1151 Industrial Motherboard, built for rugged and scalable applications. This motherboard supports a range of Intel® processors, from the entry-level Celeron to the high-performance i7, offering exceptional flexibility for various industrial and embedded systems.

Key Features:

• Dual Gigabit LAN: Featuring Intel® i211 and Intel® i219 Gigabit Ethernet ports, this motherboard ensures fast, reliable network connectivity for demanding industrial tasks, such as control systems and data-heavy applications.

• Multiple PCI Expansion Slots: With 5x PCI slots and 1x PCI-E x16 slot, as well as 1x PCI-E x4 slot, the motherboard provides ample expansion options for custom hardware configurations, making it ideal for automation and security systems.

• Storage Flexibility with 5x SATA Ports: Enjoy a wide range of storage configurations, with 5x SATA interfaces for connecting hard drives, SSDs, and other storage devices.

• Memory Support: Supports up to 4x DDR4 SODIMM memory modules, enabling fast and efficient multitasking.

• Triple Display Outputs: Includes 1x VGA and 2x HDMI ports, offering triple display capabilities for multi-monitor setups, making it perfect for digital signage, control systems, and multi-tasking environments.

• 6x COM Ports: With 6x COM ports supporting RS232/RS485/RS422, this motherboard excels in industrial communication and control applications, providing excellent serial connectivity for sensors, devices, and automation systems.

Built for high-reliability applications, this LGA1151 motherboard is the ideal choice for embedded systems, industrial automation, data centers, surveillance systems, and any application requiring robust performance, expandability, and flexibility.

Product Specifications:

• Processor Support: Intel® Core i3/i5/i7/Celeron/Pentium LGA1151 Socket

• Networking: 1x Intel® i211 Gigabit LAN, 1x Intel® i219 Gigabit LAN

• Expansion Slots: 5x PCI Slots, 1x PCI-E x16, 1x PCI-E x4

• Storage: 5x SATA Ports

• Memory: 4x DDR4 SODIMM Slots

• Display: 1x VGA, 2x HDMI (Triple Display)

• COM Ports: 6x COM Ports (RS232/RS485/RS422)

Applications:
Industrial Automation, Surveillance Systems, Data Centers, Control Systems, Embedded Computing, Digital Signage, and more.
